Fox ESS Single Phase EPS Box - Whole Home Back Up
The Fox ESS H1 6.0kW Hybrid Inverter with EPS 1PH Gen 2 is a powerful single-phase hybrid inverter designed for residential solar and battery storage applications. With dual MPPT technology, high-voltage battery compatibility, EPS backup and smart monitoring, it maximises energy efficiency while providing reliable backup power when required.
| AC Attribute | Specification |
|---|---|
| Rated Output Power | 6000W |
| Maximum Apparent Power | 6600VA |
| Maximum Output Current | 30A |
| Number of Phases | Single Phase (1PH) |
| Rated Voltage | 220 / 230 / 240V AC |
| Frequency | 50 / 60Hz |
| Power Factor | Adjustable (0.8 leading to 0.8 lagging) |
| Total Harmonic Distortion (THDi) | <3% |
| EPS Rated Output Power | 6000W |
| EPS Peak Output Power | 7200VA (60 seconds) |
| EPS Changeover Time | <20ms |
| DC Attribute | Specification |
|---|---|
| Maximum PV Array Power | 12.0kWp |
| Maximum Input Voltage | 600V |
| MPPT Voltage Range | 80–550V |
| Start-up Voltage | 75V |
| Number of MPPTs | 2 |
| Strings per MPPT | 1 / 1 |
| Maximum Input Current per MPPT | 16A / 16A |
| Maximum Short Circuit Current per MPPT | 20A / 20A |
| Battery Voltage Range | 80–480V |
| Maximum Charge Current | 40A |
| Maximum Discharge Current | 40A |
